Microlift dumbwaiter

The UK’s most popular range of dumbwaiters, ideal for various work and domestic settings. Choice of models for full flexibility means they’ve been installed in thousands of hotels, restaurants, shops, bars, pubs, and hundreds of private dwellings.

Max travel: 30m

Load capacity: 50kg, 100kg

Features & benefits

usp

Reduces manual handling hazards

Installing a dumbwaiter is a cost-effective way to reduce the risk of injury associated with manual handling and improve operational efficiency.

usp

Flexible dumbwaiter design

We offer a wide range of dumb waiter sizes and configurations. Our 50kg Microlifts are invaluable in smaller commercial settings, such as cafes or restaurants. Our 100kg models are perfect for large restaurants, hotels, and industrial settings.

usp

Reliable performance

We’ve installed over 22,000 Microlifts in the last 50 years. Many of the first are still going strong, showing we supply a reliable, hard-wearing lift backed up with regular service visits and 24/7 support to ensure long life.

Technical specifications

Predominantly moving: Goods
Speed (m/s): 0.35m/s
Travel orientation: Vertical
Capacity: 50kg, 100kg
No of people/usage: Waist height, floor level
Max no of stops: 12
Entrance configuration: Single, through, adjacent, three sides
Drive type: Smooth, quiet traction drive with precision gearbox, vee-sheave, and VVVF for superior levelling
Operation: Automatic push button control with call and send facilities at each landing
Pit depth: 0mm for counter height, 175- 600mm for floor level options
Ramp option? (Y/N): No
Headroom/clearance: 1800- 3000mm (depending on model & configuration)
Door type: Rise and fall shutters on landing and car doors. Hinged doors (option).
Shaft: Structure-supported
Power requirements: 3-phase (single-phase option)
Warranty: 1-year standard warranty, including servicing and 24/7 callout cover
