Levelmaster platform goods lift

Low rise platform goods lift. Ideal solution where goods, pallets, bins or roll cages, need to be moved over a small change in level.

Max travel: 1.5m

Load capacity: Up to 2000kg

The ideal solution for moving goods when changes in floor level can make using trolleys so difficult

In busy retail environments, back of house or warehouse stock movement, the Levelmaster, our low rise scissor lift, is perfect for negotiating small changes in floor levels.

Stannah provides you with a simple and cost-effective solution with a wide variety of platform sizes. Our Levelmaster is easy to install, requires minimal builder’s work and is the perfect solution over a small change in level.

Our Stannah Levelmaster low rise goods lift has a loading capacity of up to 2000kg, a platform with half-height sides and hardwearing finishes for excellent durability. Its robustness and flexibility make it the ideal product to move goods around safely and reduce manual handling risks.

Whether you wish to move warehouse merchandise, trolleys, pallets or loads by handcart, the Levelmaster comes with a wide variety of platform sizes and entrance configurations, with the lift platform providing safe and secure movement for goods. With these low rise platform lifts, you no longer have to worry about manual handling.

Whether moving merchandise in retail, materials in industry or anything else. You can rely on our Stannah Levelmaster.

Features & benefits

usp

Flexible design

Platform sizes that can vary to suit each individual requirement, through or adjacent entrances and flexible location of the motor control cabinet – perfect to match your requirements.

usp

Reduces manual handling hazards

Whether you wish to have an attendant to accompany your load or not, our platform goods lift range can move your goods around your building safely and reliably.

usp

Quick & easy install

An enclosed structure supporting framework makes the installation of your platform goods lift quick and easy with minimal builder’s work. The installation is typically completed within three to four days.

Technical specifications

Predominantly moving: Goods
Speed (m/s): 0.05m/s
Travel orientation: Vertical
Capacity: Up to 2000kg
No of people/usage: Floor level
Max no of stops: 2
Entrance configuration: Single
Drive type: Hydraulic
Operation: Automatic push button control with call and send facilities at each landing
Pit depth: From 90mm
Ramp option? (Y/N): Yes
Headroom/clearance: n/a
Door type: Full height door/ half-height gate (up to 3m)
Shaft: Open structure
Power requirements: 415V 50Hz 3-phase and earth
Warranty: 1-year standard warranty, including servicing and 24/7 callout cover

Technical documents

Please note: Some of our technical content requires registration to download, but you will only have to register once.
